ENGINE
Model : PERKINS 1104D-44T-TIER3A
Power : 102HP / 74,9kW@ 2200 rpm
PTO Power: 64 kW/87 hp
Maximum RPM: 2 400
Volume of engine :4 400
Air filter: Dry, dual, with indicator
TRANSMISSION
Model : Carraro 506-Up FULL SYNCHRO CARRARO TRANSMISSION
Speeds: 12 forward/12 reverse
Speed : 1,50 - 31,50 km/h
PTO
Drive: independent
Rear PTO rotation frequency, rpm: 540/540E rpm
HYDRAULICS
Working pressure: 180 bar
Pump flow rate: 48,5 l/min
Rear linkage lift capacity: 3 400 kg
Linkage category: 2
Hydraulic outputs: 8 (4 pairs)
DIMENSIONS
Length, mm : 4 112
Height, mm :2 720
Width, mm : 1 990
Front track, mm: 1 500 – 1 900
Rear track, mm: 1 500 – 1 900
Tractor weight without ballast, kg: 3 380
Front tires: 320/85-R24
Rear tires:460/85-R30
Standard equipment
Heated cab with air conditioning: standard
Differential lock: standard
Air compressor: standard
Hydraulic third-point control: standard
Front weights, kg: 10x30
Front rim weights, kg: 6x50
Rear rim weights, kg: 2x50
